7kW 20kW 30kW Movable Charger Station CCS CHAdeMO DC Fast Charging

7kW 20kW 30kW Mobile EV Charging Station CCS Level 3 Portable DC Charger .The 20kw 30kw 40KW portable quick-charger was developed for electric vehicles with CHADEMO or CCS Combo DC charging sockets and is designed for semi-mobile use. DC Portable Charger 20KW 30kw 40KW CHAdeMO CCS2 Fast Mobile Charging Station

Model: MIDA-WM-40KW

Rated voltage: DC 1000V

Input Rating: 380Vac± 15%

Power Factor: >0.99 @ full load

TFT-LCD Touch Panel: 4.3' touch display

Certification: CE ROHS

Inquiry WhatsApp Skype Email

Product Detail

Product Tags

7kW 20kW 30kW Portable Charger Station CCS CHAdeMO GBT DC Fast Charging

7kw 20kW 30kW Portable is a mobile electric vehicle (EV) charging solution tailored for commercial EVs. This unit offers businesses a more convenient way to charge electric cars, presenting an alternative to costly and challenging installations of tradition in-ground charging stations.

The 20kW 30kW Mobile Charger is a versatile solution for a variety of EV charging needs. It's a plug-and-play DC fast charger that can be easily moved to meet your charging needs, whether temporary or stationary.

The 30kW 40kW 50kW Mobile Charger meets a variety of EV charging needs, from short-term charging for cars to long-term charging for trucks, buses, speedboats, and off-highway machinery. It can be easily moved for DC fast charging at event venues, auto repair shops, warehouses, ports, construction sites, and mines. For semi-stationary charging, you can remove the wheels and anchor it to the ground.

Product Introduction

20kw 30kw Portable quick charger supports CCS and CHAdeMO only by replace the cable. USB for firmware update and RJ45 port for internet connect(optional). Open door design, it is convenient to replace power module.This charger is perfect to install for charging electric vehicle at maximum speed as well as many EV cars take in road trips through rural areas with RV or industrial areas being the main power sources for ev travelers.

Product Features

Mobile Charger 20kw 30kW Portable DC Charger Station

✔ Small size and compact design, easy for portable
✔ It is supporting CCS and CHAdeMO connector
✔ Certification: CE/IEC/ROHS
✔ Protection Degree: IP54
✔ Open door design, it is very convenient to replace power module.

Specification

AC Input	1. Input Rating:400Vac± 15%
	2. AC Input Connection:3P+N+PE (Wye connection)
	3.Max. Input Current:50A
	4.Efficiency: 95%
DC Output	1. Output Voltage Range:50~500Vdc (CHAdeMo), 150~750Vdc (CCS), 48~450Vdc(GB/T)
	2. Max.Output Power:20KW,30kW
	3Max.Output Current:50A@500V,
User Interface	1. TFT-LCD Touch Panel:4.3' touch display
	2.Push Buttons:Emergency Stop
	3. Interface:USB, RJ45
Packing	1.Dimension:630230632mm
Packing	2.Weight:35KGS
Environment	1. Operating Temperature: -20°C ~ +50°C, power derating from +50°C and above
	2. Humidity: 5% ~ 90% RH, non-condensing
	3.Altitude: 2000m
	4.IP Level: IP23
Regulation	1.Regulation: IEC61851-1
	2.Certification: CE,ROHS
	3. Charging protocol: CHAdeMO 2.0/DIN 70121/ISO15118/IEC61851-23
