Wallbox EV Charger 44kw 88kW EV Charging Station With 22kW Type 2 Cable

22kW, 44kW, and 88kW AC charging stations are available in both wall-mounted and floor-standing configurations, with output currents of 32A and 63A (dual-charger).

Inquiry WhatsApp Skype Email

Product Detail

Product Tags

Wallbox EV Charger 44kw 88kW EV Charging Station

44kw 88kw AC EV Charger Piles Type2 dual guns charger Floor Mounted EV Charging Station.

22kW, 44kW, and 88kW AC charging stations are available in both wall-mounted and floor-standing configurations, with output currents of 32A and 63A (dual-charger).

44kw/88kw Wallbox EV Type2 AC chargers are available in wall-mounted and floor mountedtypes with output current in 16A,32A and 63A(dual guns). The chargeris reliable, flexible, fast and easy to operate. It is fully tested by author-ities, suitable for public and residential parking lots, highway serviceareas, etc.

Temperature
Protection

Protection
Level IP65

Efficient
Smart Chip

Efficient
Charging

Short Circuit
Protection

EV Charging Stations Features

Innovative design:
AC type 2 socket 44kw EV charger station is an artwork designed to improve the charging experience with the breakthrough of the traditional appearance.

LED description:
The LED light shows charging status by color changes and it adopts breathing light to avoid direct glare at human eyes.

Easy to use:
User friendly design, easy for installation, maintenance and use.

Compatible with every EV:
Uses 2x22kw ev charging station with Type 2 socket that can charge any EVs on the market

Commercial 2x44kw EV Charger Station

Electrical Parameter	32A Max	63A Max
	One phase input: nominal voltage 1×230VAC 50-60 Hz
	22kW at 1x230VAC	22kW 44KW 88kw at 1x 400 VAC
Input Cord	Hard wired by licensed electrician
Output Cable & Connector	16.4FT/5.0 m cable (26.2FI/8.0m optional)
	IEC62196-2 standard compliance
Smart Grid Connecivity	Built-in Wi-Fi (Optional)(802.11 b/g/n/2.4GHz)/Bluetooth Connectivity
Firmwire	Over-the-air (OTA) upgradeable firm ware
Enironmental Parameter	Dynamic LED lights show charging status standby, charging in progress, fault indicator, network connectivity
	4.3*7.0 LCD Screen
	Protection Class IP65: Weatherproof,dust-tight
	IK08: Resistant poly carbonate case
	Quick-release wall mounting bracket include
	Operating Temperature:-22F to 122°F (-30°℃ to 50C)
Dimension	Main enclosure: 9.7inx12.8in×3.8in(300mm×160mm×120mm )
Codes & Standards	IEC 61851-1/IEC61851-21-2/IEC62196-2 compliance, OCPP 1.6
Certification	FCC ETL CE compliance
Energy Management	Home power balancing (Optional
RF1D	Optional
4G Module	Optional
Socket	Optional
Waran	2 years limited product warranty

Applicable Scenes

1. Residential charging: This 44kw ev charger station is perfect for homeowners who own a single electric vehicle and want a reliable and convenient way to charge it at home. Its compact design and high charging power make it an excellent choice for home use.

2. Workplace charging: This 2x22kw ev charging station can also be installed at workplaces, such as offices or factories, to provide employees with a convenient way to charge their electric vehicles while they work.

3. Public charging: This charger can be installed in public areas, such as on the side of a road or in a public parking lot, to provide electric vehicle owners with a convenient charging option while they are out and about.

4. Fleet charging: Businesses that operate a fleet of electric vehicles can also benefit from this charger. With its high charging power of 7kw 11KW 22KW 44kw, it can quickly charge an electric vehicle, helping to keep your fleet on the road and productive.

Overall, this dual gun smart AC 44kw EV wallbox charger is a versatile and reliable charging solution that can be used in various applications, making it an excellent investment for electric vehicle owners and businesses alike.
