1000A 1500A Liquid Cooling MCS Gun Megawatt Charging Cable

YGC1000A and YGC1500A Megawatt Charging system is based on midapower’s market-leading distributed charging system and offers maximum flexibility during the upcoming MCS transition phase.MCS Connector for connection devices for conductive charging of electric vehicles .

Model: MIDA-MCS-EV1000A

Rated voltage: DC 1000V

Rated Current: 1000A ,1500A

Therminal temperature rise: <50K

Protection Degree: IP55 Waterproof

Withstand voltage: 2000V

Working temperature: -30°C ~+50°C

Standard: IEC TS61851-23-3, IECTS63379

Certificate: CE, TUV Approved

Inquiry WhatsApp Skype Email

Product Detail

Product Tags

1000A 1500A Liquid Cooling MCS DC Charging Cable

What is MCS charging cable ?
The megawatt level charging system (MCS) is a new high-power charging solution with a charging speed much higher than traditional combined charging systems (CCS). It is specifically developed for heavy-duty pure electric vehicles, including trucks and buses.

YGC1000 and YGC1500 Megawatt Charging system is based on midapower’s market-leading distributed charging system and offers maximum flexibility during the upcoming MCS transition phase.IEC 61851-1 , IEC TS61851-23-3and IECTS63379 for connection devices for conductive charging of electric vehicles .

The Megawatt Charging System (MCS) is a charging connector under development for large battery electric vehicles. The connector will be rated for charging at a maximum rate of 3.75 megawatts.3000A 1250V.

Megawatt Charging System (MCS)" to invent a holistic system approach based on the Combined Charging System CCS. The Megawatt Charging System (MCS) Task Force represents the whole value chain of the Heavy Duty Vehicles industry segment which ensures that all perspectives are considered.

Where is the MCS Charger Cable used ?
MCS charging cable technology will provide ultra-fast charging for heavy-duty trucks, ships, and aircraft. Its application areas are extensive, covering many industries such as commercial vehicles, maritime, agriculture, mining, and aviation.

This MCS charging port, which complies with the megawatt charging system (MCS) standard, provides the charging speed, safety, and durability required for the most demanding applications, from electric heavy-duty vehicles to large energy storage systems, breaking through the limitations of traditional charging.

How to use MCS charging connector?

To use a megawatt level charging system (MCS) connector, first locate the charging port on the heavy-duty vehicle, which is typically located between the driver's side axle. Then, connect the liquid cooled MCS cable (capable of withstanding high power) to the port of the vehicle.The megawatt level charging system (MCS) is a charging connector being developed for large battery electric vehicles. The rated maximum charging power of this connector is 3.75 megawatts, 3000 amperes, and 1250 volts.

What is the MCS communication protocol?

Multipoint Communication Service Protocol Specification defines a protocol operating through the hierarchy of a multipoint communication domain. It specifies the format of protocol messages and procedures governing their exchange over a set of transport connections.

Product Introduction

1000A 1500A MCS Charging Connector Megawatt Charging System

1000A 1500A MCS (Megawatt Charging System) charging cable is a high-power charging solution designed specifically for heavy-duty electric vehicles such as trucks and buses, capable of providing up to several megawatts of power, significantly accelerating charging speed. These charging cables use dedicated connectors with sturdy and durable structures, and typically require active heat dissipation during high-power operation to safely and efficiently manage high currents.

Product Features

Key features of 1000A 1500A MCS charging cable
High power capacity: The MCS charging cable is designed to handle extremely high power, with a current rating of up to 3000 amperes and a power output of up to 3.75 megawatts.
Specially designed for heavy-duty vehicles: This system is specifically developed for large pure electric vehicles, such as long-distance trucks, buses, and other heavy-duty applications, such as electric ships and airplanes.
Durable and sturdy: MCS charging cables are designed to operate in harsh industrial environments, and many connectors have protection measures such as IP67 protection level.
Cable and connector cooling: Higher power levels (e.g. over 1 megawatt) require active cooling of connectors and cables to prevent overheating during charging.
Unique connector: The MCS connector is different from the combination charging system (CCS) used for passenger cars, although many electric trucks are now equipped with both interfaces.
