Smart 40kw 60kw 80kw DC Fast EV Charging Station Floor Mounted Stand Column Electric Vehicle

Smart 40kw 60kw 80kw DC Fast EV Charging Station Floor Mounted Stand Column Electric Vehicle

The MIDA Smart 40kw 60kw 80kw DC Fast EV Charging Station Floor Mounted Stand Column Electric Vehicle is a CE-certified, pillar-type DC fast charging station engineered for public, commercial and fleet EV charging. Offering selectable 40kW, 60kW and 80kW output from a compact wall-mounted or floor-mounted stand-column body, this Level 3 DC EV charger delivers reliable high-power charging with CCS2 connectors, OCPP smart management and full safety protection for continuous, high-traffic operation.

Core Advantages

• Selectable 40kW / 60kW / 80kW Power – one pillar-type platform scales to each site’s traffic and grid capacity.
• Fast Level 3 DC Charging – bypasses the on-board charger for far shorter charging times than AC wallboxes.
• CCS2 & Multi-Standard – CCS2 as standard, with CCS1, GB/T, CHAdeMO and NACS available by market; dual-gun models supported.
• Smart & Connected – OCPP 1.6J/2.0.1 with RFID, credit-card and app payment for commercial charging point operators.
• Outdoor-Rated & Safe – IP54/IP65, -30 C to +55 C, with full electrical protection and intelligent cooling.

Product Highlights

Flexible 40kW-80kW Power Options

Choose 40kW, 60kW or 80kW output from a single pillar-type platform. This scalable DC fast charging station lets operators match each site's traffic and grid capacity, standardizing on one wall-mounted hardware family while tuning charging speed per location.

Built for Demanding Commercial Duty

With an IP54 (IP65 optional) enclosure, a -30 C to +55 C operating range and intelligent forced-air cooling, this stand-column DC EV charger runs reliably in outdoor parking lots, gas stations and kerbside public charging points around the clock.

Smart, Networked and Payment-Ready

Running OCPP 1.6J (upgradable to 2.0.1), the commercial EV charging pile connects to third-party charging management platforms, RFID cards, credit-card terminals and mobile-app payment, giving charging point operators full remote control and billing.

Safety, Compliance and Long Service Life

CE-certified with over-voltage, over-current, over-temperature, leakage and surge protection, the floor-mounted DC fast charger safeguards vehicles and users. Modular design and remote cloud diagnostics keep uptime high and maintenance simple.

Product Specifications

Application Scenarios

This 40kW-80kW pillar-type DC EV charging station is ideal for public parking lots, retail and shopping centres, workplace and destination charging, gas stations, fleet depots and kerbside charging points. The scalable power classes and compact wall-mounted footprint let commercial operators deploy consistent hardware across many sites while matching charging speed to demand, maximizing throughput and revenue per charging bay.

After-Sales Advantages

MIDA provides a comprehensive warranty, global spare-parts support, remote cloud diagnostics and full technical documentation for every DC fast charging pile. As a manufacturer with over a decade of EV charging and energy-storage experience, MIDA supports OEM/ODM customization of branding, power configuration, connectors and regional certification.

Related MIDA Charging Solutions

Explore related high-power EV charging equipment from MIDA: MIDA 240kW 300kW 350kW Chademo CCS2 Dual Standard, 240kW 360kW 480kW Split Type DC Charging Pile, MIDA 360kW 480kW 600kW DC Supercharger Liquid Cooling, MIDA 80kW 160kW 240kW Cabinet Plus Dispenser DC.

Frequently Asked Questions (FAQ)

What is the difference between a 40kW, 60kW and 80kW wall-mounted DC fast charger?

The 40kW, 60kW and 80kW ratings refer to the maximum DC power the wall-mounted charging pile delivers to the vehicle. A 40kW unit suits destination and light commercial sites, 60kW balances speed and installed cost for retail and workplace parking, while 80kW offers the fastest turnaround for busy public and fleet locations. All three share the same compact wall-mounted or stand-column body, so operators can standardize hardware and simply select the power class that matches each site's traffic and grid capacity.

How long does a 40kW-80kW wall-mounted DC charging station take to charge an EV?

Charging time depends on the power class and the vehicle battery. As a guide, an 80kW DC fast charger can add roughly 100 km of range in about 15-20 minutes for a compatible car, a 60kW unit in about 20-30 minutes, and a 40kW unit in about 30-45 minutes. Because these are Level 3 DC chargers that bypass the on-board charger, they are far faster than AC wallboxes and ideal for commercial charging point operators.

Which connectors and protocols do the wall-mounted DC charging piles support?

The pillar-type DC EV charging stations support CCS2 as standard, with CCS1, GB/T, CHAdeMO and NACS available by market. Networking uses OCPP 1.6J, upgradable to OCPP 2.0.1, so the charger integrates with third-party charging management platforms, RFID authentication, credit-card and app-based payment, and dynamic load management.

Are the 40kW-80kW DC chargers suitable for outdoor commercial installation?

Yes. The floor-mounted stand-column and wall-mounted DC fast chargers carry IP54 (IP65 optional) ingress protection and a wide -30 C to +55 C operating range, so they perform reliably in outdoor parking lots, gas stations and kerbside sites. Intelligent forced-air cooling, over-voltage, over-current, over-temperature, leakage and surge protection keep the commercial EV charging pile safe in continuous public duty.

How does a PV DC-DC solar charging pile pair with a 40kW-80kW wall-mounted DC charger?

A PV DC-DC module takes DC power directly from a solar array and feeds it to the EV through a single DC-DC conversion stage, avoiding the double AC/DC losses of conventional charging. Combined with a 40kW-80kW wall-mounted DC charging station, it maximizes on-site solar self-consumption and lowers the cost of every kWh delivered, which is ideal for commercial car parks and green-energy charging projects.

Can the solar DC-DC charging station operate off-grid?

Yes. Off-grid and hybrid configurations combine PV input with optional battery storage, so the DC fast charger can serve remote sites and fleets with weak or no grid connection, switching seamlessly between solar, storage and grid where available.
