Liquid Cooled Split EV Charger 1000KW 1200KW DC Charging Piles Supercharger Stack

High power 1000kW 1200kW 1440kW split liquid cooled DC fast charger, 1500A 1500V output , ideal for heavy duty logistics trucks and Fleet Charging. The DC charging station with liquid-cooled charging.1200kW Commercial Rectifier Stack ,4000A Fast Charging Center,DC Split Charging Systems Commercial Electric Vehicle Charging Stations

Rate Power: 1200kw 1440kw DC Charging Station

Input Voltage: 400V±15%

Input Voltage Type: TN-S(Three Phase Five Wire)

AC Grid Frequency: 45-65Hz

Output Voltage: DC 200V-1000V

Output Voltage Error: ≤0.5％

Output Current Error: When Output current≥30A:≤±1％ When output current＜ 30A:≤±0.3A

Power Factor: ≥0.99

Leakage current: ≤10mA

Power Frequency Withstand Voltage: 2500VAC

Inquiry WhatsApp Skype Email

Product Detail

Product Tags

HPC Split EV Charging: 1000kw 1200kW1440kW Liquid Cooled EV Charger Ultra-Fast Charging Systems

High-power 1000kW/1200kW/1440kW split-type liquid-cooled DC fast charging with 1500A/1500V output is the ideal choice for heavy-duty logistics trucks and fleet charging. This DC charging station employs liquid-cooled charging technology. Additionally, 1200kW commercial rectifier units and 4000A fast-charging centers are available. Specifically designed for large public charging stations, commercial parking lots, automotive test bases, gas station energy hubs, and government/enterprise charging hubs, it offers three specifications:

480kW/960kW/1200kW. It supports 12 single-gun or 6 dual-gun terminals, enabling simultaneous charging for 12 vehicles. Compatible with CCCP 1.6J standard (independent/commercial), it comes standard with RFID and optionally supports credit card payments. With IP54/IK10 protection ratings and a working temperature range of -30°C to 55°C, it ensures stable outdoor operation. The integrated design facilitates installation and maintenance.

Technical Summary Table

Specification	MIDA HPC 1200kW	MIDA HPC 1440kW
Architecture	Split-Type (Cabinet + Satellites)	Split-Type (Cabinet + Satellites)
Max Output Voltage	150V - 1000V DC	150V - 1000V DC
Max Output Current	600A (Liquid-Cooled)	800A (Liquid-Cooled)
Efficiency	$≥$ ≥ 96.5%	$≥$ ≥ 96.5%
Power Modules	SiC High-Frequency IP65	SiC High-Frequency IP65
Communication	OCPP 1.6J / 2.0.1 / ISO 15118	OCPP 1.6J / 2.0.1 / ISO 15118
Protection Grade	Cabinet IP55 / Module IP65	Cabinet IP55 / Module IP65

High Efficiency and Energy Conservation

Ultra-wide operating temperature

Ultra-low standby power consumption

Wide output constant power range

Guaranteed Security

1000kw 1200kw 1440kW Split EV Charging Stack DC EV Charging Station

Multi-standard DC Charging Station

Simultaneously charging up to 3 EVs
- Flexible configurations 600KW 720KW 800kW 1000KW 1200KW 1440KW DC Charging Station
- Supporting CCS, CHAdeMO, GB/T, and NACS Plug
- Ethernet, Wi-Fi, 4G connection
- OCPP 1.6J & OCPP 2.0
- Smart charging supports dynamic load balancing

Easy to Use

8’’ LCD touch screen with multi-language interface
Secure authentication and payment through RFID, mobile Apps, or POS
CCS2 GB/T Plug & Charge optional
GPRS、COM、CAN2.0
480kw 600Kw 720kW 800kW CCS2 GB/T Split DC EV Fast Charging Station Charger ,Split DC Fast EV Charger Station,600kW 720kw 800kW Public Charging Station,DC Split Charging Systems Floor-mounted 480kw 720kw 800kw Commercial Electric Vehicle Charging Stations

1000kw 1200kw Split DC Charging Station

Multi-standard DC Fast Charging Station
- Supports CCS, CHAdeMO, GB/T, and AC connectors. Charging up to 3 vehicles at the same time
- Dual CCS2 ,GB/T,CHAdeMO DC Connector with Split Rapid Charger Station
- 480kw 600kw 800kw 1200kw 1440kw DC Charging Station With CCS2 GB/T CHAdeMO NACS Plug
- Split DC Charger Station 360kw 480kw 600kw 720kw 1000KW 1200KW 1440KW DC Ultra Fast Electric Vehicle Charger Station
