Dual Gun 44 kW AC EV Charger Piles Floor Mount EV Charging Station

22kw 44kw Public EV Charging Station 44kW dual plug AC public charging station .44KW EV AC Charger Station with Type1, Type2, and GBT standards. Ideal for home or commercial use. Features 5M cable, RCD protection, and smart charging options.

Inquiry WhatsApp Skype Email

Product Detail

Product Tags

EV Charging Stations Features

Innovative design:
AC type 2 cable 44kw EV charger station is an artwork designed to improve the charging experience with the breakthrough of the traditional appearance.

LED description:
The LED light shows charging status by color changes and it adopts breathing light to avoid direct glare at human eyes.

Easy to use:
User friendly design, easy for installation, maintenance and use.

Compatible with every EV:
Uses 2x22kw 44kw ev charging station with Type 2 cable that can charge any EVs on the market

2x22kw Commercial EV Charger Station

Model		7kw	14kw	22kw	44kw
Electrical specification	Power supply	1P+N+PE		3P+N+PE
	Rated voltage	230VAC		400VAC
	Frequency	50/60Hz
	Rated current	2*16A(Max)	2*32A(Max)	2*16A(Max)	2*32A(Max)
	Rated power	2*3.5kW	2*7kW	2*11kW	2*22kW
	Recommend power supply cable	3x4mm², copper	3x6mm², copper	5x4mm², copper	5x6mm², copper
	Charging plug	3.5m Cable		3.5m Cable
Functional description	Start mode	Plug-and-play/RFID card/APP*
	Display screen	4.3-inch LCD screen (display current, voltage, power, charging time, state & fault information, etc.)
	LED indicator	LED strip indicate 5 statuses (see details in LED indicator description)
	Communication interface	WIFI/Ethernet/4G(optional)
	Communication protocol	OCPP 1.6J
	Safety protection	Emergency stop button, surge protection, over/under voltage, over current, ground protection, leakage protection, over temperature
	RCD built-in	DC 6mA
Ambient conditions	Work altitude	≤ 2000 m
	Storage temperature	-30 ~ +85ºC
	Work temperature	-20 ~ +50ºC
	Operating humidity	5%-95% no condensation
	Installation location	Indoor or outdoor, good ventilation, no flammable, explosive gases
	Cooling	Natural cooling
Mechanical parameters	Net weight	<5kg		<5.5kg	<5.5kg
	Unite size	H=1500mm, W=470mm, D=300mm
	Mounting	Wall-mounted
	Mounting	Ground-mounted
	IP grade	IP 54
	Material	Metal plate shell with powder coating

Applicable Scenes

1. Residential charging: This 44kw ev charger station is perfect for homeowners who own a single electric vehicle and want a reliable and convenient way to charge it at home. Its compact design and high charging power make it an excellent choice for home use.

2. Workplace charging: This 2x22kw ev charging station can also be installed at workplaces, such as offices or factories, to provide employees with a convenient way to charge their electric vehicles while they work.

3. Public charging: This charger can be installed in public areas, such as on the side of a road or in a public parking lot, to provide electric vehicle owners with a convenient charging option while they are out and about.

4. Fleet charging: Businesses that operate a fleet of electric vehicles can also benefit from this charger. With its high charging power of 7kw 11KW 22KW 44kw, it can quickly charge an electric vehicle, helping to keep your fleet on the road and productive.

Overall, this dual gun smart AC 44kw EV wallbox charger is a versatile and reliable charging solution that can be used in various applications, making it an excellent investment for electric vehicle owners and businesses alike.
